Clean and green: PAG base oils and selected additives for Environmentally Acceptable Lubricants (EALs) and EU Ecolabel lubricants
The awareness for more sustainable lubricants has gained momentum in the machinery industry. The global sector has grown rapidly in recent years, for two main reasons:
- since 2013, the revised Vessel General Permit mandates the use of Environmentally Acceptable Lubricants (EALs) in oil-to-sea interfaces by all vessels entering US waters
- in the EU, enhanced environmental awareness in many industries has brought EU Ecolabel lubricants to the forefront of attention.
Lubricants compliant with EU Ecolabel are eligible for registration as EALs.
3 Loss categories for EU Ecolabel lubricants
(Accidental Loss Lubrication)
Closed gear oils
(Partial Loss Lubrication)
Two stroke oils
(Total Loss Lubrication)
Concrete release agents
Wire rope lubricants
Stern tube oils
Other total loss lubricants
EU Ecolabel lubricants: impressive green credentials
Clariant has much to offer formulators in this field. Polyalkylene glycols with good biodegradability can be a key component of high performing, environmentally friendly lubricants. Other typical examples of biodegradable base fluids for use in EALs are esters. While esters can perform well as lubricants, their oxidative and hydrolytic stability are usually comparatively poor. Polyalkylene glycols on the other hand do not show such drawbacks and provide the best of both worlds. Their biodegradability paves the way for use in EALs while their superior lubricating performance as well as their outstanding oxidative and hydrolytic stability allows the formulation of truly high performance lubricants.
Our Polyglykol range includes water-soluble and non-soluble PAG base oils. The grades are suitable for EU Ecolabel formulations for various applications, as they meet rigorous environmental standards. The following products are qualified
- on the EU LuSC List (Lubricant Substance Classification list), and
- comply with the latest EU Ecolabel requirements issued in 2018.
ISO VG Polyglykol
not water soluble water soluble water soluble 22 B 11/15 32 B 01/20 46 B 01/40
B 11/30 68 B 11/50 100 B 01/80
B 11/70 150 B 11/100 D 21/100 220 B 11/150 K D 21/150 320 D 21/220 460 D 21/300 1000 D 21/700 Applications Hydraulic Oil + +
Industrial Gear Oil + + Greases (ALL, PLL, TLL) + + + Stern Tube Oil + + + Metal Working Fluid + +
+: preferred choice; other grades are also possible
Polyglykol B 11/30, for example, fits the ISO VG 46 viscosity grade. It is
- suitable as base oils for hydraulic application,
- has low aquatic toxicity,
- is readily biodegradable and
- if leaked does not form a sheen on the surface of water, thanks to its excellent solubility.
Besides our PAG base oils we also offer additives to be used for EU Ecolabel formulations
Hostagliss L4 Emulsogen MTP 070 Genamin Gluco 50 Function acidic lubricity improver low foaming nonionic emulsifier Water soluble neutralizing agent Applications Greases
(ALL, PLL, TLL)
+ Metal Working Fluid + + +
